Auto Centering Vibrating Screen

Auto Centering Vibrating Screen is to solve the wet viscous material depth screening equipment, especially for less than 10mm wet sticky coal screening.

Production capacity : 1-300t/h

Scope of Application : Apply to mining, metallurgy, building materials, chemical industry and other departments for granular materials in the classification

Structure


1. Mining Self-fixed centre shale shaker is composed of sealing cover, screen box, sieve plate, dust removing mouth, exciter, soft connecting device and damping spring.

2. Mining Self-fixed centre shale shaker is the use of large amplitude, large vibration intensity, low vibration frequency and self-cleaning screen surface to complete wet viscous material screening process.

3. Mining Self-fixed centre shale shaker is not an integral part of the vibration, the screen machine side panels, roof, base is a fixed part, only the sieve plate and exciter assembly to participate in vibration.

4. Mining Self-fixed centre shale shaker is a special steel bar and frame composition, the bars were arranged vertically, the whole screen in the vibration, at the same time each bar there is also an active gap, and do secondary vibration, to maximize the elimination of wet sticky raw coal on the screen of the bonding problem.


Advantages

1. Mining Self-fixed centre shale shaker used in coal-fired power plants, are generally made of closed structure, so that dust cannot be leaked, to respond to environmental requirements.

2. Mining Self-fixed centre shale shaker with the sieve body without vibration and sieve plate vibration process characteristics, with higher amplitude, lower dynamic load advantages.

3. Mining Self-fixed centre shale shaker with fewer moving parts, vibration quality is small, so its power can be reduced to a minimum. Compared with the traditional screen machine, can reduce the power more than doubled.

4. Mining Self-fixed centre shale shaker is generally used 1-6 sets of motor drive, each motor starting time interval of 6-8 seconds. Sieve machine without material more conducive to observation and maintenance.

5. Mining Self-fixed centre shale shaker with modular, standardized components, so that the overall rapid replacement, greatly reducing on-line maintenance time.

6. Exciter end and the connection parts are equipped with protective devices, safe operation.

7. Better to solve the problem of screen plugging, high screening efficiency.

Parameters

Self-fixed centre shale shaker

Model

Specification

Max particle(mm)

Production capacity (t/h)

Motor

weight(kg)

Note

Model

Power(kw)

SZZ0918

900×1800

40

20~25

Y100L1-4

2.2

420

Hanging-type

SZZ0918

553

Seating- type

2SZZ0918

570

Seating- type

SZZ1225

1250×2500

100

100

Y132S-4

5.5

1020

Hanging-type

SZZ1225

1330

Seating- type

2SZZ1225

1320

Hanging-type

2SZZ1225

1335

Seating- type

SZZ1530

1500×3000

200

Y132M-4

7.5

1650

Hanging-type

SZZ1530

1700

Seating- type

2SZZ1530

2870

Hanging-type

SZZ1540

1500×4000

100

90-200

Y160L-4

15

3412

Seating- type

2SZZ1540

1500×4000

100

250

Y160L-4

15

4240

Seating- type

SZZ1836

1800×3600

150

300

Y180M-4

18.5

4500

Hanging-type

2SZZ1836

5616

Seating- type
